1.1.10

VDR Software

The playback module accompanies the base model VDR and is installed on the download Client
PC. Additional playback software is available for use in shore-side offices. This additional
software is necessary for the playback of data on the RSM or other media once it has been
removed from the ship and transported to the office environment.
In addition, the playback software may be supplied for shoreside use.
Software installed on client PC includes:
1. VDR Playback application
2. VDR Download application
Optionally, the following software may also be purchased:
3. VDR Real Time Display Module
4. Graphical Analysis
Software included on the CD that accompanies the VDR:
Data Recovery CD
1. VDR Download application
2. VDR Playback application
Install CD
1. Audio Config Suite
2. Data Extraction
3. FRM download application
4. Product Key updater
5. VDR Config Utility
6. VDR Download application
7. VDR Parameters (.ini file)
8. VDR Playback application
9. VDR utility
10. VDR apps Folder
11. Video Config Suite
12. NMEA Config
1.2

Client/Playback PC

Only a certified technician can connect a PC service laptop to the DMM via an Ethernet
connection. This PC can be used to configure the VDR using a remote desktop.
This PC can also be used to copy, download and playback data; to autoarchive; and to display
real-time NMEA and video data.
The download/playback software, which is supplied as part of the system, offers the following
features:
Plug and play with automatic display configuration;
Password-protected (general playback and audio);
Multiple display capability and output to Electronic Chart Display and Information System
and Electronic Chart Display;
User-friendly controls with search and fast forward features.
NOTE: Software associated with the optional Client PC is described in Appendix 5: Playback
Software.
