In the example above, Audio Module Channels 2 and 3 (containing input connections for
microphones 1, 2, 3, and 4) are mixed on OutPutChannel2. Audio Module Channels 4 and 5
(containing input connections for microphones 5, 6, 7, and 8) are mixed on OutPutChannel3.
Audio Module Channel 6 is mixed on OutPutChannel4. This arrangement allows all bridge
microphones to be recorded to the FRM. The engine control room mics are not recorded in the
FRM BUT would be recorded on the DMM along with all other microphone data.
Note! The NumOutputChannels field must equal the number of OutPutChannelX
fields that are in use.
