9.5.7

Info Tab

Selecting the Info tab of the Video Configuration Utility opens the Info page. It provides statistics
on the capture image.
The Histogram window displays the histogram for the image.
The Cross-Section window (indicated by the dashed red line) shows a graph of the current
cross-section of the image, as well as minimum and maximum values of Red, Green, and Blue on
the cross-section line.
Channel Selection lets the user enable or disable which color channels are selected or
deselected. For example the installer can disable Green.
The Status controls at the bottom of the page enable the installer to display information about the
image such as:
BPP (bits per pixel);
Image size;
Cursor position;
RGB value at the cursor position;
Viewing bounds; and
Zoom level.
9.5.7.1

VCS2 Menu Overview

This section provides an overview of the menu items available in the Video Diagnostics
application.
1. File Menu
•
Load Bitmap: Selecting this option opens a file selection window from which a user must
choose a saved bitmap file to load to the Image window for viewing.
•
Save Bitmap: This will save the current image to a bitmap file.
•
Save Histogram: This will save the Histogram from the Info page to a CSV file (Comma
Separated Value file).
•
Save Cross-Section: This will save the cross-section of pixel data indicated by the dashed
red line in the Capture window to a CSV file.
•
Exit: This will exit the application.
2. View Menu
•
Zoom In: Zooms into the image.
•
Zoom Out: Zooms out of the image.
•
Fit to Window: Will cause the image the edges of the image to fill to the edges of the Image
window.
•
Full Screen: This sets the Video Configuration Utility to Full-Screen mode. Right click on the
image in Full-Screen mode to access the menu.
3. Toolbar
•
Load: Load a bitmap, same as File->Load Bitmap.
•
Pan Tool: Activate the Panning tool for the Image Window. This is the default.
•
Eyedropper Tool: Activate the Eyedropper tool to choose a pixel and get the value.
•
Zoombox Tool: Activate the ZoomBox tool, which lets the user select an area to zoom.
•
Zoom 1:1: Zooms to the original scale of the image.
•
Zoom In: Increase the zoom magnification.
•
Zoom Out: Decrease the zoom magnification.
•
Fit to Window: Display the full image in the window.
