7. Select the 'Advanced' tab and press the 'Settings' button in the 'Network Connection
Settings' section.
8. Press the 'Add' button and in the "Service Settings" window:
Enter Video TCP in the 'Description of service' field.
Enter 192.168.199.228 in the 'Name or IP address' field.
Enter 3659 in the 'External Port number for this service' field.
Enter 3659 in the 'Internal Port number for this service' field.
Select the TCP radio button.
Press 'OK'.
9. Press the 'Add' button and in the Service Settings window:
Description of service:
Name or IP address':
External Port number for this service:
Internal Port number for this service:
Select the UDP radio button.
Press 'OK'.
10. Press OK in the Advanced Settings window;
11. Press OK in the Windows Firewall window;
12. Press 'Close' in the Local Area Connection Properties window;
13. Install VCS2 on the Service PC; and
14. Run VCS2 on the service PC.
VDR-100G3/G3S Installation Manual
Chapter 9: Video Module, Rev. 1.2
Enter Video UDP
Enter 192.168.199.228
Enter 2649
Enter 2649
