Customize Entries In The Vidchanx.ini Files - Rutter VDR-100G3 Installation Manual

Typical
Parameter
Value
HPOL1 1
VPOL1 1
XCLAMPPOL1 -1
XCOASTPOL1 1
PreCoast1 0
PostCoast1 0
SyncThreshold1
VCO1 2
CPmp1 6
N1 0
Typical
Parameter
Value
RGain1 75
GGain1 75
BGain1 75
ROff1 128
GOff1 0
BOff1 0
CVolt1 0
CPlace1 8
CLength1 20
VideoFormat1 1
9.5.1.1

Customize Entries in the VidChanX.ini Files

Each entry in the <VidChanX.ini> file indicates the voltage level, timing, and signal characteristics
of the video source. The values generated by Video Configuration Utility (VCS2) are based on
VESA and Industry Standards and are adequate in order to capture initial images.
If a video capture does not initiate, the most likely reason is that the VPOL1 field may be set
wrong. The Video Configuration Utility (VCS2), If provided with a channel number, will capture
and save a sample image to verify the proper state of the VPOL1 field. The image will be saved
to the filename <TestImage.bmp>. The image will be annotated with a calibration grid to verify
proper video alignment.
In certain rare cases it may be necessary to optimize the video to correct the colour balance.
VDR-100G3/G3S Installation Manual
Chapter 9: Video Module, Rev. 1.2
Remarks
0 or 1. HSYNC Polarity
- Changing this value will increase margin at the left of the image
- Choose the value which produces the widest margin, and then
adjust with XDim1
0 or 1. VSYNC Polarity
Captured images will not be rectangular if incorrect value is chosen
-1=Internal, 0= Negative, or 1= Positive.
-1=Internal, 0= Negative, or 1= Positive.
0 to 255. Number of clock synchronization pulses to skip prior to
COAST signal
0 to 255. Number of clock synchronization pulses to skip after
COAST signal
0 to 255. For composite signals only, used to differentiate a VSYNC
from a HSYNC
Must be present and must be same value as in [CLOCK] section
Must be present and must be same value as in [CLOCK] section
Must be present and must be same value as in [CLOCK] section
Table 9-4 - SYNCS Parameters
Remarks
0 to 255. Specifies A/D range for the red video line.
0 to 255. Specifies A/D range for the green video line.
0 to 255. Specifies A/D range for the blue video line.
0 to 255. Specifies DC offset for the red video line.
0 to 255. Specifies DC offset for the green video line.
0 to 255. Specifies DC offset for the blue video line.
0 = clamp to min voltage. 1 = clamp to midscale.
Specifies when clamp occurs in pixel clocks from trailing edge of
HSYNC.
Specifies number of black pixels that participate in the DC restore
clamp circuitry.
RADAR = 1, CHART = 2
Table 9-5 - VIDEO Parameters
9-6
06/10/2008
