VDR-100G3/G3S TECHNICAL SPECIFICATIONS

The following tables contain a summary of the technical specifications for the Rutter VDR-100G3
system components:
2.1

Power Consumption

Normal Operating Current (approx.)
Maximum Current Draw (approx.)
Recommended Ship Main Breaker
2.2

DPU Specifications

Weight
Dimensions
Input Power
Output Power
Data Ports
Battery Backup Power
Data Storage Capacity
VDR-100G3/G3S Installation Manual
0.80 A @220VAC
0480 A @120VAC
1.2 A @220VAC
2.1 A @120VAC
10 A @220VAC
10 A @120VAC
20.2 Kg
457 x 457 x 150mm (H x W x D)
85 -264 VAC 50-60Hz
24VDC to FRM, Audio, Video, NMEA, Alarm Module, optional Remote
Storage and optional interfaces
Ethernet input from Audio, Video, and NMEA Modules
Ethernet Output to FRM
Ethernet Output / Download PC
RS232 Input/Output for Alarm Module
USB and optional remote storage
2 Hrs @ -15 Deg C for Audio system, Alarm Module, DMM, and FRM
The internal HDD is 160GB
Current Data = 4.88GB
Internal Secured Data = 20G
Internal Archived Data = 124GB
(NOTE: Some storage reduction due to drive partitioning)
USB memory stick
External Archived data
