[AUDIO]
blocks =60
// VDR-100G3
ChannelEnabled1 = 1
ChannelEnabled2 = 1
ChannelEnabled3 = 1
ChannelEnabled4 = 1
ChannelEnabled5 = 0
ChannelEnabled6 = 0
ChannelEnabled7 = 0
ChannelEnabled8 = 0
// Software mixing - provide list of channels to mix (max. 2 per channel)
// Use comma for OutputChannelx if 2 channels are mixed i.e. 1,2
NumOutputChannels = 4
OutputChannel1 = 1
OutputChannel2 = 2
OutputChannel3 = 3
OutputChannel4 = 4
OutputChannel5 = 5
OutputChannel6 = 6
OutputChannel7 = 7
OutputChannel8 = 8
numVHFChannels = 1
VHF-Channel1 = 1
VHF-Channel2 = 5
MikesOnMixer1 = 2
MikesOnMixer2 = 2
MikesOnMixer3 = 2
MikesOnMixer4 = 0
MikesOnMixer5 = 0
MikesOnMixer6 = 0
MikesOnMixer7 = 0
DetectionThreshold1 = 500
DetectionThreshold2 = 500
DetectionThreshold3 = 500
DetectionThreshold4 = 500
DetectionThreshold5 = 500
DetectionThreshold6 = 500
ChirpLength = 30
MikeRetryInterval = 3600
MaxMikeRetrys = 11
[VIDEO]
numSources = 1
transferRate = 15000
blocks = 4
maxColors = 256
enhancedCompression = 0
noiseClipping = 0
recordDuringPowerFail = 0
[NMEA]
transferRate = 1000
blocks =60
TimeSourcePort = 3
timeString = ZDA
timeMuxID = 12
AISLocation = 3
EnableAISParsing = 0
AISMuxID = 11
recordDuringPowerFail = 0
[ALARM]
Port = COM1
Baudrate = 4800
VDR-100G3/G3S Installation Manual
Appendix 3: VDRPARAMS.INI File, Rev. 1.2
// 0 = disabled, 1 = enabled
// default is 1
// default is 1
// 0 to 2; first non-VHF channel
// test signal RMS must exceed this to be detected
// test signal RMS must exceed this to be detected
// test signal RMS must exceed this to be detected
// test signal RMS must exceed this to be detected
// test signal RMS must exceed this to be detected
// test signal RMS must exceed this to be detected
// mike self-test signal length, in ms (100 ms max)
// in seconds
// retry this many times before declaring failure
// 1 to 4, default is 2
// 1 video = 15000, 2=7500, 3=5000, 4=3750
// maximum number of colors in output image;
// ignored if enhancedCompression is enabled
// 1 = enable, default is 0
// 1 = enable, default is 1; ignored if enhancedCompression is disabled
// To record Video during a power failure, set value to 1; default = 0
// 500 to 1000 ms, default is 1000
// port that time signal is on, 3 = UDP, 1 or 2 = Serial Port
// PC, ZDA, GGA, GLL, RMC
// GPS mux channel - used for GPS Error
// 1 = COM1, 2 = COM2, 3 = mux, default = 3
// 1 = no AIS data to FRM, default is 0
// MUX ID where AIS data is located; only read if AISLocation is 3
// To record NMEA during a power failure, set value to 1; default = 0
// default is 4800
