Fast Forward Rate: Specify the rate at which to fast forward the playback of the current data set.
Playback Data Rewind: When clicked, rewinds playback to the interval specified in the Playback
Data Rewind Time dropdown menu.
Playback Data Rewind Time: Select the time interval to rewind the playback of the current data
set when the Playback Data Rewind button is clicked.
Note! Many of the controls available during Playback mode are not applicable
during Real Time Display mode therefore they are disabled (grayed).
Select Playback | Set Playback Rate from the main menu to adjust the speed of the replay. A
dialog box will appear requiring a time compression rate. Enter any integer from 2 to 24
(inclusive) in the text box provided and click OK (see Figure 21 - Set Fast Forward Rate).
The Controls toolbar can be hidden by deselecting Controls from the View menu. By default it is
visible therefore a check will appear adjacent to this option. Deselecting it will remove this check
mark.
A5.11 Audio Volume & Channel Selection
Audio data includes continuous bridge audio and radio communications. The configuration of
audio will differ between ships but is generally arranged in 2 to 4 banks.
Individual channels contain audio data corresponding to an area of the bridge, bridge wings, or
radio communications. Each channel may be reviewed individually or in conjunction with other
channels during playback. For example, a user may wish to play back audio data recorded in the
centre of the bridge while turning off external microphones where wind noise may be present.
VDR-100G3/G3S Installation Manual
Appendix 5: Playback Software, Rev. 1.1
Figure 21 - Set Fast Forward Rate
