10. Move the Ethernet cable to the Download port;
11. Confirm that communication with the capsule is available using the DOS command to
ping 200.200.200.100.
12. Return the fixed capsule's Ethernet cable to the FRM port.
12.4.4.3

Changing the IP of the JoTron Float-free SFRM Capsule

The IP address on the JoTron Float-free SFRM Capsule must be changed to be in the same IP
segment as the download port of the VDR. To change the IP address of the JoTron Float-free
SFRM Capsule:
1. Disconnect the primary capsule from the FRM port—this will be replaced later.
2. Confirm the IP of the FRM Ethernet port on the DMM is in the same segment as the
default IP address of the JoTron Float-free SFRM Capsule (i.e. 192.168.0.189) The last
number can be any number from 2 to 254 except 37;
3. Connect the JoTron Float-free SFRM Capsule to the FRM Ethernet port and confirm that
communication is available via the ping command. Refer to Section 12.3.2.3: Connecting
the JoTron Float-free SFRM Capsule;
4. Press Enter;
5. From Windows Internet Explorer, type in the address http://192.168.0.37 and select the
Config button;
6. To change the IP address of the JoTron Float-free SFRM Capsule enter the Admin
password "jotadmin";
7. Click "Login"
8. In the "Select IP address to use" field' enter the new IP address 200.200.0.37;
9. Click OK
10. Click the "Save and Reboot" button to save these settings
Figure 12–21 - JoTron Float-free SFRM Capsule Web Interface
