Altera Cyclone III Reference Manual page 73

Table 2–51. DDR2 Interface I/O (Part 3 of 6)
Board
Reference
U11 pin H7 Data 34
U11 pin H3 Data 35
U11 pin H1 Data 36
U11 pin H9 Data 37
U11 pin F1 Data 38
U11 pin F9 Data 39
U26 pin H1 Data 4
U11 pin C8 Data 40
U11 pin C2 Data 41
U11 pin D7 Data 42
U11 pin D3 Data 43
U11 pin D1 Data 44
U11 pin D9 Data 45
U11 pin B1 Data 46
U11 pin B9 Data 47
U12 pin G8 Data 48
U12 pin G2 Data 49
U26 pin H9 Data 5
U12 pin H7 Data 50
U12 pin H3 Data 51
U12 pin H1 Data 52
U12 pin H9 Data 53
U12 pin F1 Data 54
U12 pin F9 Data 55
U12 pin C8 Data 56
U12 pin C2 Data 57
U12 pin D7 Data 58
U12 pin D3 Data 59
U26 pin F1 Data 6
U12 pin D1 Data 60
U12 pin D9 Data 61
U12 pin B1 Data 62
U12 pin B9 Data 63
Altera Corporation
March 2008
Description
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
SSTL18 Class 1
Reference Manual
Schematic
I/O Standard
Signal Name
DDR2_DQ34
DDR2_DQ35
DDR2_DQ36
DDR2_DQ37
DDR2_DQ38
DDR2_DQ39
DDR2_DQ4
DDR2_DQ40
DDR2_DQ41
DDR2_DQ42
DDR2_DQ43
DDR2_DQ44
DDR2_DQ45
DDR2_DQ46
DDR2_DQ47
DDR2_DQ48
DDR2_DQ49
DDR2_DQ5
DDR2_DQ50
DDR2_DQ51
DDR2_DQ52
DDR2_DQ53
DDR2_DQ54
DDR2_DQ55
DDR2_DQ56
DDR2_DQ57
DDR2_DQ58
DDR2_DQ59
DDR2_DQ6
DDR2_DQ60
DDR2_DQ61
DDR2_DQ62
DDR2_DQ63
Cyclone III Development Board
Board Components
Cyclone III
Device Pin
Number
A11
C13
D15
C12
E14
D13
AD17
B7
C11
A7
C10
E11
B6
H13
D10
C17
B19
AH23
B18
C19
D20
C16
A19
E17
C21
C22
A21
A22
AE19
C24
B21
D21
E18
2–63
