Table 2–33. 7-Segment Display Pin-Out (Part 2 of 2)
Board
Reference
U30 pin 10
User-defined display select signal
U30 pin 4
User-defined display select signal
U30 pin 6
User-defined display select signal
Figure 2–7. 7-Segment Display
Table 2–34. 7-Segment Display Component Reference and Manufacturing Information
Board
Description
Reference
U30
7-segment, green LED
display
Altera Corporation
March 2008
Description
1
The four-pin, 7-segment display uses fewer pins than 2-digit,
7-segment displays. See
Table 2–34
lists the 7-segment display component reference and
manufacturing information.
Manufacturer
Lumex, Inc.
Reference Manual
I/O
Schematic
Standard
Signal Name
1.8 V
SEVEN_SEG_SEL3
1.8 V
SEVEN_SEG_SEL4
1.8 V
SEVEN_SEG_MINUS
Figure
2–7.
Manufacturing
Part Number
LDQ-M2212R1
Cyclone III Development Board
Board Components
Cyclone III
Device
Pin Name
E4
C3
G19
Manufacturer
Web Site
www.lumex.com
2–37
