Communication Ports & Interface Cards
Table 2–48. HSMC Port B Interface Signal Names, Descriptions, and Type (Part 3 of 4)
Board
Reference
J9 pin 107
LVDS RX 9p or CMOS I/O data bit 45 LVDS or 2.5 V
(is this
suppose to
be 108?)
J9 pin 108
LVDS TX 9n or CMOS I/O data bit 46 LVDS or 2.5 V
(is this
suppose to
be 109?)
J9 pin 110
LVDS RX 9n or CMOS I/O data bit 47 LVDS or 2.5 V
J9 pin 113
LVDS TX 10p or CMOS I/O data bit 48 LVDS or 2.5 V
J9 pin 114
LVDS RX 10p or CMOS I/O data bit 49 LVDS or 2.5 V
J9 pin 115
LVDS TX 10n or CMOS I/O data bit 50 LVDS or 2.5 V
J9 pin 116
LVDS RX 10n or CMOS I/O data bit 51 LVDS or 2.5 V
J9 pin 119
LVDS TX 11p or CMOS I/O data bit 52 LVDS or 2.5 V
J9 pin 120
LVDS RX 11p or CMOS I/O data bit 53 LVDS or 2.5 V
J9 pin 121
LVDS TX 11n or CMOS I/O data bit 54 LVDS or 2.5 V
J9 pin 122
LVDS RX 11n or CMOS I/O data bit 55 LVDS or 2.5 V
J9 pin 125
LVDS TX 12p or CMOS I/O data bit 56 LVDS or 2.5 V
J9 pin 126
LVDS RX 12p or CMOS I/O data bit 57 LVDS or 2.5 V
J9 pin 127
LVDS TX 12n or CMOS I/O data bit 58 LVDS or 2.5 V
J9 pin 128
LVDS RX 12n or CMOS I/O data bit 59 LVDS or 2.5 V
J9 pin 131
LVDS TX 13p or CMOS I/O data bit 60 LVDS or 2.5 V
J9 pin 132
LVDS RX 13p or CMOS I/O data bit 61 LVDS or 2.5 V
J9 pin 133
LVDS TX 13n or CMOS I/O data bit 62 LVDS or 2.5 V
J9 pin 134
LVDS RX 13n or CMOS I/O data bit 63 LVDS or 2.5 V
J9 pin 138
LVDS TX 14p or CMOS I/O data bit 64 LVDS or 2.5 V
(is this
suppose to
be 137?)
J9 pin 139
LVDS TX 14p or CMOS I/O data bit 65 LVDS or 2.5 V
(is this
suppose to
be 138?)
J9 pin 139
LVDS RX 14n or CMOS I/O data bit 66 LVDS or 2.5 V
J9 pin 140
LVDS RX 14n or CMOS I/O data bit 67 LVDS or 2.5 V
J9 pin 143
LVDS RX 15p or CMOS I/O data bit 68 LVDS or 2.5 V
2–58
Cyclone III Development Board
Description
Reference Manual
Schematic
I/O Standard
Signal Name
HSMB_TX_P9
HSMB_RX_P9
HSMB_RX_N9
HSMB_TX_P10
HSMB_RX_P10
HSMB_TX_N10
HSMB_RX_N10
HSMB_TX_P11
HSMB_RX_P11
HSMB_TX_N11
HSMB_RX_N11
HSMB_TX_P12
HSMB_RX_P12
HSMB_TX_N12
HSMB_RX_N12
HSMB_TX_P13
HSMB_RX_P13
HSMB_TX_N13
HSMB_RX_N13
HSMB_RX_P14
HSMB_TX_N14
HSMB_TX_P14
HSMB_RX_N14
HSMB_TX_P15
Cyclone III
Device Pin
Number
W25
R22
R23
Y25
T25
Y26
T26
AA25
U27
AA26
U28
AB25
U22
AB26
V22
Y23
W28
Y24
W27
V23
AE28
AE27
V24
W22
Altera Corporation
March 2008
