Table 2–8. Board-Specific LEDs (Part 2 of 2)
Board
LED Name
Reference
D1 10 Mb
D3 100 Mb
D4 1000 Mb
D6 Duplex
D18 HSMC Port A
present
D19 HSMC Port B
present
D17 SRAM active
D23 Flash active
Table 2–9. Board-Specific LEDs Component Reference and Manufacturing Information
Board Reference
D1, D3, D4, D6-D8, Green LED, 1206, SMT,
D17-D19, D20, clear lens, 2.1 V
D22-D25
D5 Blue LED, 1206, SMT,
clear lens, 3.5 V
D21 Red LED, 1206, SMT,
clear lens, 2.0 V
Altera Corporation
March 2008
Illuminates when Ethernet PHY is using the 10 Mbps connection speed.
Driven by the Marvell 88E1111 PHY.
Illuminates when Ethernet PHY is using the 100 Mbps connection speed.
Driven by the Marvell 88E1111 PHY.
Illuminates when Ethernet PHY is using the 1000 Mbps connection speed.
Driven by the Marvell 88E1111 PHY. Also connects to Cyclone III FPGA.
Illuminates when Ethernet PHY is both sending and receiving data. Driven by
the Marvell 88E1111 PHY.
Illuminates when HSMC Port A has a board or cable plugged such that pin
160 becomes grounded.
Illuminates when HSMC Port B has a board or cable plugged such that pin
160 becomes grounded.
Illuminates when SRAM is being accessed with a read or write transaction.
Driven by the MAX II CPLD.
Illuminates when flash memory is being accessed with a read or write
transaction. Driven by the MAX II CPLD.
Table 2–9 lists the board-specific LEDs component reference and
manufacturing information.
Description Manufacturer
Lumex, Inc
Lumex, Inc
Lumex, Inc
Power Display (U28)
The power being measured by the MAX II CPLD and associated A/D is
displayed on a dedicated 7-segment display connected to the MAX II
device called Power Display. Although the 7-segment display is connected
to the MAX II CPLD, it is also register-controllable from the FPGA using
the FSM bus.
Reference Manual
Board Components
Description
Manufacturing
Part Number
SML-LX1206GC-TR
SML-LX1206USBC-TR www.lumex.com
SML-LX1206IC-TR
Cyclone III Development Board
Manufacturer
Web Site
www.lumex.com
www.lumex.com
2–21
