Verilog code to help you get started quickly with your own designs. The development board includes an Altera Cyclone III FPGA configured with a hardware reference design stored in flash memory. Hardware designers can use the development board, along with example designs included in the kit, as a platform to prototype complex embedded systems.
The Cyclone III Development Kit CD-ROM contains the following documents: ■ Readme.txt—Contains special instructions and refers to the kit documentation. ■ Cyclone III Development Kit User Guide (this document)—Describes how to use the kit. ■ Cyclone III 3C120 Development Board Reference Manual—Provides specific...
2. Getting Started Introduction This user guide familiarizes you with the contents of the kit and guides you through the Cyclone III development board setup. Using this guide, you can do the following: ■ Inspect the contents of the kit ■...
Verify that all components are on the board and appear intact. In typical applications with the Cyclone III development board, a heatsink is not necessary. However, under extreme conditions the board may require additional cooling to stay within operating temperature guidelines. You may wish to perform power consumption and thermal modeling to determine whether your application requires additional cooling.
References Hardware Requirements The Quartus II software has some minimum system requirements. Otherwise, the Cyclone III development kit provides all of the hardware needed to use the board. For Quartus II requirements, refer to the Altera website at www.altera.com/products/software/products/quartus2web/sof-quarwebmain.html. Software Requirements This kit requires the following software: ■...
CD-ROM drive and double-click on the setup.exe file. 2. Follow the on-screen instructions to complete the installation process. The installation program copies the Cyclone III development kit files to the computer hard disk and creates a Programs > Altera > Cyclone III Development Kit <version#>...
Altera Complete Design Suite at www.altera.com/support/software/download/nios2/dnl- nios2.jsp. The Nios II soft-core embedded processor runs on Altera FPGAs. Some of the reference designs included in this development kit use the Nios II processor. Load the Altera Complete Design Suite DVD into the DVD player, and click Install free package on the startup screen.
To install it, go to www.altera.com/support/software/drivers/usb-blaster/dri-usb- blaster-xp.html. Licensing Considerations Before using the Quartus II software, you must request a license file from the Altera website at www.altera.com/licensing and install it on your computer. When you request a license file, Altera emails you a license.dat file that enables the software.
Quartus II software installed on the host computer ■ USB-Blaster driver software installed on the host computer. The Cyclone III development board includes integrated USB-Blaster circuitry for FPGA programming. Host computer and development board cannot communicate without the USB-Blaster driver software installed. For installation information, refer “Installing the USB-Blaster Driver”...
Page 16
4–2 Chapter 4: Development Board Setup Powering Up the Board Figure 4–1. Cyclone III Development Board Layout and Components DDR2TOP_ACTIVE LED (D11) Cyclone III FPGA (U20) Power LED (D5) MAX II CPLD (U7) DDR2 SDRAM Device Interface MAX II Device...
Page 18
4–4 Chapter 4: Development Board Setup Configuring the FPGA To configure the Cyclone III FPGA, perform the following steps: 1. Verify that the 4-position SW3 mini-DIP switches and the two jumpers are set to the default positions shown in Table 4–2.
5. Power Measurement Introduction One of the main features of the Cyclone III FPGA device is its low power consumption. You can measure the power used by the 3C120 FPGA device on the Cyclone III development board for various conditions with a power design example provided with the kit.
J9. LED7 (AF19), signal o_noutput_ena_state, lights to indicate that the outputs are enabled and toggling. Enabling the outputs further increases power for each resource utilization percentage used by the Cyclone III FPGA. 7. Press the User_PB3 button again to disable the outputs. LED7 turns off.
5–2. Changing the Design Example The development kit includes source code for the Cyclone III power design example so you can use it as a starting point for your own measurements. The design example uses 19 stamp.v modules, each with 8 outputs, for a total of 152 output pins.
6. Design Tutorials Introduction The example designs and tutorials included in the Cyclone III Development Kit help familiarize new users with development board features. My First FPGA Design Tutorial My First Nios II Software Tutorial provide step-by-step guidance for the first-time user.
A. Programming the Flash Device Overview There is a Common Flash Interface (CFI) type flash memory device on the Cyclone III development board. When you first receive the kit, this CFI flash device arrives programmed with a default factory configuration that was loaded from a Programmer Object File (.pof).
