10. Using the two bolts (2), mount each stabilizing attachment (1) removed in
the inside of the power cabinet so that both attachments are housed in the cabinet
(see
They can be mounted on the rear of the power cabinet. The stabilizing attachments are
stored at the top and bottom, above and below each other.
11. Fully tighten the four bolts that were temporarily tightened in
bus bar brackets on the expansion cabinet to the base cabinet.
Use a torque wrench to secure the bus bar (fixed at 8.24 N·m; 84 kgf·cm).
12. Connect the connectors between the expansion cabinet and power cabinet (see
FIGURE 3-16
13. Attach the side cover that was removed in
14. Attach the side cover that was removed in
cabinet.
3.4
Connecting Cables
This section explains how to connect cables.
Section 3.4.1, "Connecting the power cords" on page 3-24
■
Section 3.4.2, "Connecting a UPS Unit" on page 3-32
■
Section 3.4.3, "Cable Connection Between the Base and Expansion Cabinets of the
■
M9000 Server" on page 3-34
Section 3.4.4, "Connecting the Administration Console" on page 3-46
■
3.4.1
Connecting the power cords
Connect the input power cords to the server.
Note – The connection procedure for the input power cords for the single-phase power feed
differs from the three-phase power feed. Follow the appropriate procedure for connecting the
cords.
3-24
SPARC Enterprise M8000/M9000 Servers Installation Guide • October 2012
).
FIGURE 3-13
).
Step 5
Step 4
to the power cabinet.
Step 1
to the right side of the power
Step 7
to
and secure the
