Connecting Cables

These topics explain how to connect the data and power cables to the server:
Step Description
1. Review the cabling requirements.
2. Review I/O port connector details.
3. Connect the management and data
cables.
4. Secure cables in the CMA.

Cabling Requirements

Review these cabling notes before attaching cables to the server.
Minimum cable connections for the server:
■
At least one server on-board Ethernet network connection (NET port)
■
The SER MGT port
■
The NET MGT port
■
A power cable for each power supply
■
SP management ports: There are two management ports for use with the SP.
■
The SER MGT port uses an RJ-45 cable and is always available. This port is the
■
default connection to the SP.
The NET MGT port is the optional connection to the SP. This port becomes
■
available after you configure network settings for the SP (through the SER MGT
port).
The NET MGT port uses an RJ-45 cable for a 10/100 BASE-T connection. This
port does not support connections to Gigabit networks.
Links
"Cabling Requirements" on page 39
"Identifying Ports" on page 40
"Connecting Data and Management
Ports" on page 44
"Secure Cables in the CMA" on page 48
