FIGURE 3-19
5. On the bus bar of the power cabinet, attach two bus bar brackets supplied as
accessories (1) with four bolts, and tighten the bolts temporarily.
Note – Temporary tightening of bus bar brackets makes it easier to perform
6. Move the power cabinet so that it is on the right side of the expansion cabinet.
7. Remove the stabilizing attachments that are mounted on the bottom at the front and
rear of the power cabinet (see
a. Remove the two screws (1) securing the stabilizing attachment.
b. Remove the two bolts (2) securing the stabilizing attachment.
8. Connect the expansion cabinet and power cabinet using the six (6) bolts supplied as
accessories.
Mount the connecting bolts in the direction indicated by the arrows in
3-22
SPARC Enterprise M8000/M9000 Servers Installation Guide • October 2012
Removing the Right Side Cover From the Power Cabinet
).
FIGURE 3-11
Step
11.
.
FIGURE 3-20
