Single-Phase Power Supply System (M8000 Server)
FIGURE 2-1
Dual-power
feed system
Power feed A
Power feed B
distribution board
distribution board
Note – (1) To connect multiple input cords of the server to the customer's distribution panel,
the input cords must be independently connected to outlets on the basis of a one-to-one
correspondence as shown in
Note – (2) Connect the power feed A and the power feed B (for
separate AC power supply from each other.
(Note 1)
(Note 2)
.
FIGURE 2-1
Chapter 2 Preparing to Install the System
to a
dual-power feed)
