Connecting the Server Cables

This topic describes how to connect cables to the server.
Step Description
1 Review the cabling requirements.
2 Review the front and rear panel connectors
and ports.
3 Connect management and data cables.
4 Secure cables with the CMA.
Related Information
"Confirming Server and Site Specifications" on page 1
■
"Installing the Server" on page 15
■
"Powering On the Server for the First Time" on page 45
■

Cabling Requirements

Minimum cable connections for the server:
■
■
■
■
■
Service processor management ports: There are two service processor
■
management ports for use with the ILOM service processor.
At least one server on-board Ethernet network connection (NET port)
The service processor serial management port (SER MGT port)
The service processor network management port (NET MGT port)
Power cables for the server power supplies
Links
"Cabling Requirements" on page 35
"Front Panel Components" on page 3
"Rear Panel Components" on page 4
"Identifying Ports" on page 37
"Connecting Data and Management Cables"
on page 40
"Secure Cables Using the CMA" on page 42
