3.4.3.1

Connecting Cables Between XSCF Units

1. Connect the XSCF units in the base and the expansion cabinets using a clock cable.
Connect them so that the label on each XSCF unit matches the label on the connector of
the cable.
2. Use a flathead screwdriver to secure the data cable connectors.
TABLE 3-3
Cable Type
Data cable
Data cable
Connecting Cables Between XSCF Units
FIGURE 3-31
Base cabinet
XSCFU_B#0
B0
3.4.3.2

Connecting Cables Between CLKUs

1. Connect the Clock control units (CLKUs) in the base cabinet and the expansion
cabinet using a clock cable and data cable.
When the cables are connected, each label on the CLK unit must match the label of each
cable.
Note – Refer to
CLK unit.
Cable Correspondence
Base Cabinet
XSCFU_B#0
XSCFU_B#1
XSCFU_B#1
B1
Data cable
Section A.2, "M9000 Server Views" on page A-4
Expansion Cabinet
XSCFU_C#0
XSCFU_C#1
Expansion cabinet
XSCFU_C#0
C0
Data cable
Chapter 3 Installing the Server
XSCFU_C#1
C1
for the location of the
3-35
