Cable Correspondence (For One Pair Of XB Units)
TABLE 3-5
Cable Type
Base Cabinet
Data cable
XBU_B#0
Data cable
XBU_B#0
Data cable
XBU_B#0
Data cable
XBU_B#0
Data cable
XBU_B#0
Data cable
XBU_B#0
Clock cable
XBU_B#0
* Indicates a slot number (#0 to #7) of the XB unit of the base cabinet.
† Indicates a slot number (#8 to #15) of the XB unit of the expansion cabinet.
Connecting Cables Between XB Units (For Example, For One Pair)
FIGURE 3-33
Base cabinet
XBU#0
DT#0 DT#1 DT#2
Yellow
Pink
Brown
Green
Orange
Blue
Colored tie wraps
3-38
SPARC Enterprise M8000/M9000 Servers Installation Guide • October 2012
Expansion Cabinet
*
-DT#0
XBU_B#8
*
-DT#1
XBU_B#8
*
-DT#2
XBU_B#8
*
-DT#3
XBU_B#8
*
-DT#4
XBU_B#8
*
-DT#5
XBU_B#8
*
-CL
XBU_B#8
DT#3 DT#4 DT#5
Expansion Cabinet
†
-DT#0
Yellow
†
-DT#1
Pink
†
-DT#2
Brown
†
-DT#3
Green
†
-DT#4
Orange
†
-DT#5
Blue
†
-CL
-----
Expansion cabinet
XBU#8
DT#0 DT#1 DT#2
Data cable
Clock cable
DT#3 DT#4 DT#5
