10. Using hook and loop fasteners, secure the DT#0, DT#1, and DT#2 cables to the cable
holder along the side of the base cabinet.
For the secured fastener location, see (6) of
11. Connect XBU#1 and XBU#9 with the DT#3, DT#4, and DT#5 cables in this order.
Use a flathead screwdriver to secure the data cable connectors.
Note – Refer to the Note located before
12. Using a hook and loop fastener, secure the DT#3, DT#4, and DT#5 cables to the cable
holder along the side of the expansion cabinet.
For the secured fastener location, see (7) in
13. Connect XBU#1 and XBU#9 with the clock cable. Use a torque screwdriver to secure
the clock cable connector with the torque of 0.2 N·m; 2.0 kgf·cm, and lay the clock
cables on the data cables.
Note – If you are unable to obtain a torque screwdriver, finger tighten the clock cable
connectors. Do not secure them with a regular screwdriver.
Note – Do not secure the clock cables to the cable folder along with the data cables.
Note – Refer to the Note located before
14. Set the data cables and the clock cables on the brackets between the base cabinet and
the expansion cabinet.
.
FIGURE 3-34
Step 1 when you connect the cable.
.
FIGURE 3-35
Step 1 when you connect the cable.
Chapter 3 Installing the Server 3-43
