Power Supply Connection Specifications
TABLE 2-3
Name Destination
M8000 Japan
Server
North
America,
General
Overseas
Europe
M9000 Japan
Server
North
America
General
Overseas
* The power cord length is the length from the cord port on the cabinet to the outlet plug.
† The plugs for the North America and general overseas markets may be replaced locally as required. Make sure that the facility administrator or a
qualified electrical engineer performs the replacement work.
‡ A primary power feed server without the dual power feed option does not have a redundant power cord. All power cords in the primary power feed
server must be kept connected and under power.
Power
*
Cord Length Plug Type
3.0 m (9.8 ft) 30 A-250 V 3P,
locking type plug
(NEMA L6-30P)
3.0 m (9.8 ft) NEMA L6-30P
3.0 m (9.8 ft) EN60309 (32 A)
3.0 m (9.8 ft) 30A-250V 3P,
locking type plug
(NEMA L6-30P)
3.0 m (9.8 ft) NEMA L6-30P
3.0 m (9.8 ft) EN60309 (32A)
‡
Number of Plugs
3 (single-power feed)
6 (dual-power feed)
†
3 (single-power feed)
6 (dual-power feed)
3 (single-power feed)
6 (dual-power feed)
Base cabinet
5 (single-power feed)
10 (dual-power feed)
Base cabinet + expansion
cabinet
10 (single-power feed)
20 (dual-power feed)
†
Base cabinet
5 (single-power feed)
10 (dual-power feed)
Base cabinet + expansion
cabinet
10 (single-power feed)
20 (dual-power feed)
Base cabinet
5 (single-power feed)
10 (dual-power feed)
Base cabinet + expansion
cabinet
10 (single-power feed)
20 (dual-power feed)
Chapter 2 Preparing to Install the System
**
Outlet in Facility
30 A-250 V 3P, locking
type (NEMA L6-30R)
Embedded type: 3320-
L6 <American Denki>
Exposed type: 3321-L6
<American Denki>
NEMA L6-30R (North
America only)
EN60309 (32 A)
30 A-250 V 3P, locking
type (NEMA L6-30R)
Embedded type: 3320-
L6 <American Denki>
Exposed type: 3321-L6
<American Denki>
NEMA L6-30R (North
America only)
EN60309 (32 A)
