Sun Oracle SPARC Enterprise M9000 Installation Manual page 49

Note – Unless otherwise stated, assume that you are facing the front of the power cabinet
when you perform the work. There is a power supply unit (PSU) on the front of the power
cabinet. For information on the mounting location, see
Moving the Filler Panel of the Power Cabinet
FIGURE 3-18
1
4. Remove the six (6) screws securing the right side cover of the power cabinet and
remove the cover.
The removed cover will be remounted in
and
FIGURE A-5
2
Step 13.
Chapter 3 Installing the Server
.
FIGURE A-7
3-21
