Rail Mounting Bracket Release Button (Either Server)
FIGURE:
8. Verify that the CMA retracted without binding.
9. Adjust the cable straps and CMA as required to secure the cables.
See
"Managing Cables With the CMA" on page
Connecting the Server Cables for Both
Servers
To boot the server, you must connect and configure the network and serial ports. The
procedures are given in the following sections.
"Managing Cables With the CMA" on page 42
"Dismounting the Servers" on page 43
The servers also have serial and USB ports available for connections to optional
devices. See
"Port, Connector, and LED Locations for Both Servers" on page 12
more information.
42.
Installing the SPARC Enterprise T5120 and T5220 Servers
for
37
