11.5
Main View
Illustration 29: Screenshot of Spatial FOG Manager main view
11.5.1
Serial Port
The serial port dialogue is used to connect to Spatial FOG Dual. You should select a
serial port and baud rate and click connect. The default baud rate of Spatial FOG Dual
is 115200. The connection indicator displays whether there is communication with a
Spatial FOG Dual unit.
11.5.2
Attitude Indicator
The aircraft style attitude indicator shows roll and pitch through a virtual horizon.
Around the sides heading, speed and height are shown. All units are SI (metric) and
degrees.
Spatial FOG Dual Reference Manual
Page 52 of 138
Version 1.0
26/06/2015
