13.9.31

Local Magnetic Field Packet

Packet ID
Length
Field Bytes
# Offset
1 0
2 4
3 8
Table 73: Local magnetic field packet
13.9.32

Odometer State Packet

Packet ID
Length
Field Bytes
# Offset
1 0
2 4
3 8
4 12
5 16
6 17
Table 74: Odometer state packet
13.9.33

External Time Packet

Packet ID
Length
Field Bytes
# Offset
1 0
2 4
Table 75: External time packet
Local Magnetic Field Packet
Data Size
Type
fp32 4
fp32 4
fp32 4
Odometer State Packet
Data Size
Type
s32 4
fp32 4
fp32 4
fp32 4
u8 1
3
External Time Packet
Data Size
Type
u32 4
u32 4
Spatial FOG Dual Reference Manual
Description
Local magnetic field X (mG)
Local magnetic field Y (mG)
Local magnetic field Z (mG)
Description
Odometer pulse count
Odometer distance (m)
Odometer speed (m/s)
Odometer slip (m)
Odometer active
Reserved
Description
Unix time (seconds), see section 13.9.1.4
Microseconds, see section 13.9.1.5
Page 113 of 138
Version 1.0
26/06/2015
50
12
51
20
52
8
