Illustration 13: Spatial FOG Dual mated connector clearance
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
Table 15: Pin allocation table for Spatial FOG Dual connector
8.11

Spatial FOG Dual Evaluation Cable Harness

Advanced Navigation offers a pre-terminated evaluation cable harness for quick
connection to Spatial FOG Dual. All external signal and power connections are
provided with 2 metres of cable. For quick testing in applications, the interface cable is
Colour
Black
Brown
Red
Orange
Yellow
Green
Blue
Violet
Grey
White
White/Black
White/Brown
White/Red
Spatial FOG Dual Reference Manual
Page 28 of 138
Version 1.0
26/06/2015
Function
GPIO 1
GPIO 2
Signal Ground
Power Ground
Power Supply
Primary RS422 Rx(+) / RS232 Rx
Primary RS422 Rx(-)
Primary RS422 Tx(+) / RS232 Tx
Primary RS422 Tx(-)
Auxiliary RS232 Tx
Auxiliary RS232 Rx
GNSS RS232 Rx
GNSS RS232 Tx
