8.6

Communication Specifications

Parameter
Interface
Speed
Protocol
Peripheral Interface
GPIO Level
Table 12: Communication specifications
8.7

Hardware Specifications

Parameter
Operating Voltage
Input Protection
Power Consumption
Backup Battery Capacity
Backup Battery Charge Time
Backup Battery Endurance
Operating Temperature
Environmental Sealing
MTBF
Shock Limit
Dimensions
Weight
Table 13: Hardware specifications
Spatial FOG Dual Reference Manual
Page 25 of 138
Version 1.0
26/06/2015
Value
RS422 (RS232 optional)
4800 to 10M baud
AN Packet Protocol
2x GPIO
1x Auxiliary RS232
1x GNSS corrections RS232
5 V or RS232
Value
9 to 36 V
-40 to 100 V
510 mA @ 12 V (typical)
> 48 hrs
30 mins
> 10 years
-40 °C to 75 °C
MIL-STD-810G
> 36,000 hours
94 x 94 x 95 mm
740 grams
IP68
25 g
