13.10.7.3
Auxiliary RS232 Transmit Functions
Value
0
7
12
39
40
41
42
Table 106: Auxiliary RS232 transmit functions
13.10.7.4
Auxiliary RS232 Receive Functions
Value
0
6
8
9
11
19
20
21
22
42
Table 107: Auxiliary RS232 receive functions
Spatial FOG Dual Reference Manual
Description
Inactive
NMEA Output
ANPP Output
TSS1 Output
Simrad 1000 Output
Simrad 3000 Output
Serial Port Passthrough
Description
Inactive
NMEA Input
Novatel GNSS Input
Topcon GNSS Input
ANPP Input
RTCM Differential GNSS Corrections Input
Trimble GNSS Input
u-blox GNSS Input
Hemisphere GNSS Input
Serial Port Passthrough
Page 132 of 138
Version 1.0
26/06/2015
