Deployment Guide for Maximum Security Environments

Viewing Network Interface and System Status

Network Interface Status

20
The network interface status is indicated by the lights on the network interface
module.

Quad BRI Network Interface Status Lights

The network interface lights are located on the network interface module.
Indicator Light
Green and yellow lights off
Green light on
Yellow light on
Green and yellow lights on

PRI Network Interface Status Lights

The network interface lights are located on the network interface module.
Indicator Light
Green and yellow lights off
Red light on or blinking
Connection Status
Indicates one of the following situations:
• No power to the system.
• The system is not connected to the
network.
• The system is not receiving a clock
signal from the network.
• The system is restarting.
The system is receiving a clock signal
from the network.
The system is able to make a call.
Indicates one of the following situations:
• The system is receiving a software
update.
• The system is operating normally.
Connection Status
No power to the system.
Indicates one of the following situations:
• The system is not connected to the
ISDN network.
• There is a problem with the ISDN
line.
