INVT GD200-037G/045P-4 Operation Manual page 149

Goodrive200 inverters
Function
code
reverse rotation in
vector control
Keypad setting for
P03.16 upper frequency of
forward rotation
Keypad setting for
P03.17 upper frequency of
reverse rotation
electromotion
P03.18
Upper braking
P03.19
Keypad setting of
P03.20 electromotion
Keypad setting of
P03.21
braking torque
P17.09 Output torque
P17.15 Torque reference
Name
3: AI3
4:Pulse frequency HDI setting upper-limit
frequency
5:Multi-step setting upper-limit frequency
6:MODBUS communication setting upper-limit
frequency
7~9: Reserved
0.00Hz~P00.03 (the Max. frequency)
0.00 Hz~P00.03 (the Max. frequency)
Upper 0:Keypad setting upper-limit frequency(P03.20
sets P03.18, P03.21 sets P03.19)
torque
1: AI1
source
2: AI2
3: AI3
4: HDI
torque
5:MODBUS communication
source
6~8: Reserved
0.0~300.0%( rated current of the motor)
torque
0.0~300.0%( rated current of the motor)
-250.0~250.0%
-300.0~300.0%( rated current of the motor)
Detailed instruction of parameters
148
Basic operation instruction
Default
value
50.00 Hz
50.00 Hz
180.0%
180.0%
0.0%
0.0%
0
0
