INVT GD200-037G/045P-4 Operation Manual page 114

Goodrive200 inverters
Function
Name
code
Output
P09.09 upper limit
of PID
Output
P09.10 lower limit
of PID
Feedback
offline
P09.11
detection
value
Feedback
offline
P09.12
detection
time
P09.13 PID
Detailed instruction of parameters
stability of the system.
Setting range:0.0~100.0%
These parameters are used to set the upper and
lower limit of the PID adjustor output.
100.0 % corresponds to Max. frequency or the
Max. voltage of ( P04.31)
Setting range of P09.09: P09.10~100.0%
Setting range of P09.10: -100.0%~P09.09
Set the PID feedback offline detection value,
when the detection value is smaller than or equal
to the feedback offline detection value, and the
lasting time exceeds the set value in P09.12, the
inverter will report "PID feedback offline fault" and
the keypad will display PIDE.
Setting range of P09.11: 0.0~100.0%
Setting range of P09.12: 0.0~3600.0s
0x0000~0x1111
113
Function codes
Default
Modify
value
○
100.0%
○
0.0%
○
0.0%
○
1.0s
○
0x0001
