INVT GD200-037G/045P-4 Operation Manual page 167

Goodrive200 inverters
Function
code
P06.17 Lower limit of AO1 output
Corresponding AO1
P06.18
output to the lower limit
P06.19 Upper limit of AO1 output
The corresponding AO1
P06.20
output to the upper limit
P06.21 AO1 output filter time
P06.22 Lower limit of AO2 output
Corresponding AO2
P06.23
output to the lower limit
P06.24 Upper limit of AO2 output
Corresponding AO2
P06.25
output to the upper limit
P06.26 AO2 output filter time
P06.27 Lower limit of HDO output 0.0%~P06.25
Corresponding HDO
P06.28
output to the lower limit
P06.29 Upper limit of HDO output P06.23~100.0%
P06.30 Corresponding HDO
Name
9:Output torque
10:Analogy AI1 input value
11:Analogy AI2 input value
12:Analogy AI3 input value
13:High speed pulse HDI input value
14:MODBUS communication set value 1
15:MODBUS communication set value 2
16~21:Reserved
22: Torque current (the rated current of
the motor)
23: Ramp reference frequency(with sign)
24~30: Reserved
0.0%~P06.15
0.00V~10.00V
P06.13~100.0%
0.00V~10.00V
0.000s~10.000s
0.0%~P06.20
0.00V~10.00V
P06.18~100.0%
0.00V~10.00V
0.000s~10.000s
0.00~50.00kHz
0.00~50.00kHz
Detailed instruction of parameters
166
Basic operation instruction
Default
value
0.0%
0.00V
100.0%
10.00V
0.000s
0.0%
0.00V
100.0%
10.00V
0.000s
0.00%
0.0kHz
100.0%
50.00kHz
