INVT GD200-037G/045P-4 Operation Manual page 254

Goodrive200 inverters
The inverter
GD200-1R5G-4
GD200-2R2G-4
GD200-004G/5R5P-4
GD200-5R5G/7R5P-4
GD200-7R5G/011P-4
GD200-011G/015P-4
GD200-015G/018P-4
GD200-018G/022P-4
GD200-022G/030P-4
GD200-030G/037P-4
GD200-037G/045P-4
GD200-045G/055P-4
GD200-055G/075P-4
GD200-075G/090P-4
GD200-090G/110P-4
GD200-110G/132P-4
GD200-132G/160P-4
GD200-160G/185P-4
GD200-185G/200P-4
GD200-200G/220P-4
GD200-220G/250P-4
GD200-250G/280P-4
GD200-280G/315P-4
GD200-315G/350P-4
GD200-350G/400P-4
GD200-400G-4
GD200-500G-4
Recommended cable size(mm
R,S,T
PE
U,V,W
2.5 2.5
2.5 2.5
2.5 2.5
4 4
6 6
10 10
10 10
16 16
25 16
25 16
35 16
50 25
70 35
95 50
120 70
150 70
185 95
240 95
120*2P 150
120*2P 150
150*2P 150
150*2P 150
185*2P 185
185*2P 185
95*4P 95*2P
95*4P 95*2P
120*4P 95*2P
253
2
)
P1(+) PB(+)(-)
2.5 2.5
2.5 2.5
2.5 2.5
2.5 2.5
4 2.5
6 4
10 4
10 6
16 10
16 10
25 16
35 25
50 25
70 35
95 35
120 70
150 95
185 50
95*2P 50
95*2P 50
95*2P 50
120*2P 95
120*2P 95
120*2P 95
150*2P 120
150*2P 120
95*4P 120
Appendix C
Screw
Termin
Tightening
al
torque
screw
(Nm)
size
M4 1.2~1.5
1.2~1.5
M4
1.2~1.5
M4
M5 2-~2.5
M5 2-~2.5
M5 2-~2.5
M5 2-~2.5
M6 4~6
M6 4~6
M8 9~11
M8 9~11
M8 9~11
M10 18~23
M10 18~23
M10 18~23
M12
31-40
M12 31-40
M12
31-40
M12 31-40
M12
31-40
M12 31-40
M12 31-40
M12
31-40
M12 31-40
M12
31-40
M12
31-40
M12 31-40
