INVT GD200-037G/045P-4 Operation Manual page 172

Goodrive200 inverters
Set
value
22 ACC/DEC time selection 2
23 Simple PLC stop reset
24 Simple PLC pause
25 PID control pause
Traverse pause (stop at the
26
current frequency)
Traverse reset (return to the
27
middle frequency)
28
29 Torque control prohibition
30 ACC/DEC disabling
31
32
33 increasing/decreasing setting
Function
Counter reset
Counter trigging
Length reset
Frequency
temporal clear
terminals.
Terminal Terminal
1 2
OFF OFF
ON OFF
OFF ON
ON ON
Restart simple PLC and clear the memory state of
PLC.
Program pause during PLC implement. Run at the
current speed step. After cancel the function, simple
PLC continues to run.
Temporal PID invalid and the inverter will output at the
current frequency.
The inverter will stop at the current output and after
canceling the function, the inverter will continue to
traverse run at the current frequency.
The setting frequency of the inverter will come back to
the middle frequency.
Counter clear
Switch from torque control mode to speed control
mode
Ensure the inverter will not be affected by the external
signals (except for the stopping command) and keep
the current output frequency.
Enable the pulse counter.
Length counter clear
When the terminal closes, the frequency set by
UP/DOWN can be cleared. All set frequency will be
restored into the reference frequency by the
frequency command channel and the frequency will
171
Basic operation instruction
Instructions
ACC/DEC time Corresponding
selection
ACC/DEC time 1 P00.11/P00.12
ACC/DEC time 2 P08.00/P08.01
ACC/DEC time 3 P08.02/P08.03
ACC/DEC time 4 P08.04/P08.05
parameter
