INVT GD200-037G/045P-4 Operation Manual page 102

Goodrive200 inverters
Function
Name
code
Jumping
P08.12 frequency
range 2
Jumping
P08.13 frequency
3
Jumping
P08.14 frequency
range 3
Traverse
P08.15
range
Sudden
jumping
P08.16
frequency
range
Traverse
P08.17
boost time
Traverse
P08.18 declining
time
Detailed instruction of parameters
Setting range: 0.00Hz ~P00.03
(the Max. frequency)
This function applies to the industries where
traverse and convolution function are required
such as textile and chemical fiber.
The traverse function means that the output
frequency of the inverter is fluctuated with the set
frequency as its center. The route of the running
frequency is illustrated as below, of which the
traverse is set by P08.15 and when P08.15 is set
as 0, the traverse is 0 with no function.
Traverse range: The traverse running is limited
by upper and low frequency.
The traverse range relative to the center
frequency: traverse range AW＝center frequency
×traverse range P08.15.
Sudden jumping frequency＝traverse range AW
×sudden jumping frequency range P08.16.
When run at the traverse frequency, the value
101
Function codes
Default
Modify
value
○
0.00Hz
○
0.00Hz
○
0.00Hz
○
0.0%
○
0.0%
○
5.0s
○
5.0s
