Goodrive200 inverters
Set
value
Shifting between A setting
13
Shifting between A setting
14
and combination setting
Shifting between B setting
15
and combination setting
16 Multi-step speed terminal 1
17 Multi-step speed terminal 2
18 Multi-step speed terminal 3
19 Multi-step speed terminal 4
20 Multi-step speed pause
21 ACC/DEC time selection 1
Function
clear
and B setting
Frequency increasing/decreasing setting clear
terminal can cancel the assistant channel frequency
set by the internal UP/DOWN of the inverter to make
the reference frequency restore to the frequency
reference by the main reference frequency channel.
This function can realize the shifting between the
frequency setting channels.
th
The 13 function can realize the shifting between A
frequency reference channel and B frequency
reference channel.
th
The 14 function can realize the shifting between A
frequency reference channel and the combination
setting channel set by P00.09
th
The 15 function can realize the shifting between B
frequency reference channel and the combination
setting channel set by P00.09
The 16 step speeds can be set by the combination of
digital state of four terminals.
Note: multi-step speed 1is the low position, multi-step
speed 4 is the high position.
Multi-step Multi-step
speed 4 speed 3
BIT3 BIT2
Shield the multi-step speed selection terminal function
to keep the setting value at the current state.
Select 4 ACC/DEC time by the combination of the 2
170
Basic operation instruction
Instructions
Multi-step
speed 2
BIT1
Multi-step
speed 1
BIT0
