7.13.3.

Measure the packet loss rate (with OpS)

Connect the OpS terminal to the WT (Master) and measure the packet loss rate in the following
procedure.
Step 1: Select the Traffic Information tab.
Step 2: Set "Display Interval" under "Traffic Acquisition."
Step 3: Select Save File as ON or OFF.
Step 4: Click the Execute button under "Traffic Acquisition" to start traffic measurement.
Step 5: After traffic measurement for any length of time, click the Abort button under
"Traffic Acquisition" to end traffic measurement.
Step 6: Check "Packet Loss Rate."
Step 2
Step 4
Figure 7-58 Measure the packet loss rate
7-148
Step 1
Step 3
Step 5
