Goodrive300-16 special inverter for HVAC
Function
Name
code
Emergency
stop
P22.48
deceleration
time

A.3 Goodrive300-16 communication additions

1. MODBUS communication
Function
instruction definition
Communication
control
command
The address of
communication
setting
Detailed instruction of parameters
than P22.47.
0.0~600.0s
Address
Data meaning instruction
2000H 0009H: emergency deceleration to stop
PID1 reference 1, range (0~1000, 1000
2002H
corresponds to 100.0%)
PID1 feedback 1, range (0~1000, 1000
2003H
corresponds to 100.0%)
Special control command word
Bit6:=1 fire mode enabling
=0: fire mode disabling
Bit7:=1 HVAC invalid enabling
=0: HVAC invalid disabling
Bit8:=1 hibernation triggering enabling
2009H =0: hibernation triggering disabling
Bit9:=1 hibernation waking enabling
=0: hibernation waking disabling
Bit10:=1 PID2 start enabling
=0: PID2 start disabling
Bit11:=1 PID2 stop enabling
=0: PID2 stop disabling
PID1 reference 2, range (0~1000, 1000
200FH
corresponds to 100.0%)
PID1 feedback 2, range (0~1000, 1000
2010H
corresponds to 100.0%)
2011H PID2 reference, range (0~1000, 1000
124
Appendix A
Default
Modify
value
○
2.0s
R/W
characteristics
W/R
W/R
W/R
W/R
W/R
W/R
W/R
