Goodrive300-16 special inverter for HVAC
Function
Name
code
PZD2
P15.13
sending
PZD3
P15.14
sending
PZD4
P15.15
sending
PZD5
P15.16
sending
PZD6
P15.17
sending
PZD7
P15.18
sending
PZD8
P15.19
sending
PZD9
P15.20
sending
PZD10
P15.21
sending
PZD11
P15.22
sending
P15.23 PZD12
Detailed instruction of parameters
14: Bacnet read input function parameter
15: Bacnet write input function parameter
16: Bacnet write input function code
17: PID1 reference source 2, range(0~1000,1000
corresponds to 100.0%)
18: PID1 feedback source 2, range(0~1000,1000
corresponds to 100.0%)
19: PID2 reference source 1, range(0~1000,1000
corresponds to 100.0%)
20: PID2 feedback source 1, range(0~1000,1000
corresponds to 100.0%)
21: Water level of inlet sump, range(0~1000,1000
corresponds to 100.0%)
0: Invalid
1: Running frequency(*100,Hz)
2: Setting frequency(*100,Hz)
3: Bus voltage(*10,V)
4: Output voltage(*1,V)
5: Output current (*10,A)
6: Output torque actual value(*10,%)
7: Output power actual value(*10,%)
8: Running rotating speed(*1,RPM)
9: Running linear speed (*1,m/s)
10: Ramp given frequency
11: Fault code
12: AI1 value (*100,V)
13: AI2 value (*100,V)
14: AI3 value (*100,V)
15: PULSE frequency value (*100,kHz)
16: Terminals input state
17: Terminals output state
18: PID1 reference(*100,%)
19: PID1 feedback(*100,%)
20: Motor rated torque
101
Appendix A
Default
Modify
value
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
