INVT Goodrive 300-16 Operation Manual page 9

Goodrive300-16 special inverter for HVAC
Function
PID function
Overload capability
Starting torque
Protection function
Analog input
Analog output
Digital input
Peripheral
interface Digital output
Communication
Communication
extension interface
Relay extension card
Mountable method
Temperature of the
running environment
Average non-fault
Protective degree
Others
DC reactor
2 sets of PID
G type: 150% of rated current: 60 seconds
180% of rated current: 10 seconds
200% of rated current: 1 second
P type: 120% of rated current: 60 seconds
0.3Hz 150% (sensorless vector control)
More than 30 protection functions, including
overvoltage, overcurrent, overheating and phase
loss
2 0~10V/0~20mA and 1 -10~10V
2 0~10V/0~20mA
8 common inputs, the Max. frequency: 1kHz,
selectable PNP/NPN
1 high speed input, the Max. frequency: 50kHz
2 programmable relay outputs, NO and NC;
1 high speed pulse output
Standard 485 interface, available RTU protocol
Available Profibus DP, DeviceNet, BACnet and
CANopen
6 programmable relay outputs, NO
Wall and flange mountable
-25~55℃, derate above 40℃, If temperature is
above 40℃, derate 1% for every additional 1℃.
2 years (25℃ ambient temperature)
time
IP20
Safety Meet CE requirements
Cooling Forced air-cooling
Unavailable for 30kW and below, available for 37kW
above
Built-in C3 filters: meet the degree requirement of
EMC filter
IEC61800-3 C3
Specification
8
Product overview
