Goodrive300-16 special inverter for HVAC
3.4.2 Commissioning steps of basic functions
1. Check the circuits and ensure proper wiring;
2. P00.18=1, restore to factory default;
3. Input the parameters of motor name plate to P2 group and do motor autotuning;
4. P22.00=1, enable HVAC function;
5. P22.10=1, enable circulation variable frequency motor;
6. According to the actual situations, set multiple function codes of P22.11~P22.18 to 1 and
enable multiple circulation variable frequency motors; set the function codes to 2 and enable
power frequency motors;
7. According to the motor number, such as A and B, set P06 group;
8. Proper running and commissioning
3.4.3 List of control parameters
List of relevant function parameters (take 3 circulation variable frequency motors+2 power
frequency motors for example)
Function
code
P00.00 Speed control mode
Run command
P00.01
Max. output
P00.03
frequency
Upper limit of
P00.04
running frequency
Lower limit of
P00.05
running frequency
P00.11 ACC time 1
DEC time 1
P00.12
S1 terminals function
P05.01
S2 terminals function
P05.02
P06.03 Relay RO1 output
P06.04 Relay RO2 output
Name
value
channel
50.00Hz
50.00Hz
20.00Hz
4.0s
4.0s
Set
2 V/F control
Terminal control, adjustable according to
1
the actual situations
Adjustable according to the actual
situations
Adjustable according to the actual
situations
Adjustable according to the actual
situations
Adjustable according to the actual
situations
Adjustable according to the actual
situations
1 Forward running
7 Fault reset
34 Connect motor A variable frequency
35 Connect motor A power frequency
22
Commissioning guidelines
Remark
