Goodrive300-16 special inverter for HVAC
Function
Name
code
Module
P15.01
address
PZD2
P15.02
receiving
PZD3
P15.03
receiving
PZD4
P15.04
receiving
PZD5
P15.05
receiving
PZD6
P15.06
receiving
PZD7
P15.07
receiving
PZD8
P15.08
receiving
PZD9
P15.09
receiving
PZD10
P15.10
receiving
PZD11
P15.11
receiving
PZD12
P15.12
receiving
Detailed instruction of parameters
0~127
0: Invalid
1: Setting frequency (0~Fmax(unit:0.01Hz))
2: PID1 reference source 1, range(0~1000,1000
corresponds to 100.0%)
3: PID1 feedback source 1, range(0~1000,1000
corresponds to 100.0%)
4: Torque setting (-3000~3000,1000 corresponds
to 100.0% the rated current of the motor)
5: Upper frequency of forward rotation
(0~Fmax unit:0.01Hz))
6: Upper frequency of reverse rotation
(0~Fmax(unit:0.01Hz))
7: Electromotion torque upper limit (0~3000,1000
corresponds to 100.0% of the rated current of the
motor)
8: Braking torque upper limit (0~2000,1000
corresponds to 100.0% of the rated current of the
motor)
9: Virtual input terminals command
Range: 0x000~0x1FF
10: Virtual output terminals command
Range: 0x00~0x0F
11: Voltage setting value(special for V/F
separation )(0~1000,1000 corresponds to 100.0%
the rated voltage of the motor)
12: AO output set value 1(-1000~1000,1000
corresponds to 100.0%)
13: AO output set value 2(-1000~1000,1000
corresponds to 100.0%)
100
Appendix A
Default
Modify
value
◎
2
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
