INVT Goodrive 300-16 Operation Manual page 51

Goodrive300-16 special inverter for HVAC
Function
Name
code
coefficient
in constant
power zone
Lowest
weakening
P03.23 point in
constant
power zone
Max.
P03.24
voltage limit
Pre-excitin
P03.25
g time
Weak
magnetic
P03.26
proportiona
l gain
Vector
P03.27 control
speed
P04 Group V/F control
Motor 1 V/F
P04.00 curve
setting
Torque
P04.01 boost of
motor 1
Torque
P04.02
boost close
Detailed instruction of parameters
10%~100%
0.0~120.0%
0.000~10.000s
0~8000
0: Display the actual value
1: Display the setting value
0: Straight line V/F curve
1: Multi-dots V/F curve
th
2: 1.3 power low torque V/F curve
th
3: 1.7 power low torque V/F curve
th
4: 2.0 power low torque V/F curve
5: Customized V/F(V/F separation)
0.0%: (automatic) 0.1%~10.0%
0.0%~50.0% (relative to the rated frequency of
motor 1)
50
Appendix A
Default
Modify
value
○
20%
◎
100.0%
○
0.300s
○
1000
○
1
◎
0
○
0.0%
○
20.0%
