INVT Goodrive 300-16 Operation Manual page 56

For hvac
Table of Contents

Advertisement

Goodrive300-16 special inverter for HVAC
Function
Name
code
S2
terminals
P05.02
function
selection
S3
terminals
P05.03
function
selection
S4
terminals
P05.04
function
selection
S5
terminals
P05.05
function
selection
S6
terminals
P05.06
function
selection
S7
terminals
P05.07
function
selection
S8
terminals
P05.08
function
selection
HDI
terminal
P05.09
function
selection
Detailed instruction of parameters
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10: Increasing frequency setting (UP)
11: Decreasing frequency setting (DOWN)
12: Frequency setting clear
13: Shift between A setting and B setting
14: Shift between combination setting and A setting
15: Shift between combination setting and B setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi- step speed terminal 4
20: Multi- step speed pause
21: ACC/DEC time 1
22: ACC/DEC time 2
23: Simple PLC stop reset
24: Simple PLC pause
25: PID1 control pause
26: Traverse pause (stop at the current frequency)
27: Traverse reset (return to the center frequency)
28: Counter reset
29: Torque control disabling
30: ACC/DEC disabling
31: Counter trigging
32: Reserved
33: Cancel the frequency change setting
temporarily
34: DC brake
35: Shift the motor 1 into motor 2
36: Shift the command to the keypad
55
Appendix A
Default
Modify
value
4
7
0
0
0
0
0
0
