INVT Goodrive 300-16 Operation Manual page 24

Goodrive300-16 special inverter for HVAC
Function
code
P06.05 Relay RO3 output
P06.06 Relay RO4 output
P06.07 Relay RO5 output
P06.08 Relay RO6 output
P06.09 Relay RO7 output
P06.10 Relay RO8 output
P09.02 Max. PID1 reference
Upper limit of PID1
P09.03
reference
Lower limit of PID1
P09.04
reference
PID1 reference
P09.05
source 1
ACC/DEC time of
P09.09
PID1 reference
PID1 feedback
P09.10
source 1
P09.16 Output feature
P09.17 Proportional gain
P09.18 Integral time
P09.19 Differential time
P22.00 HVAC function
P22.01 Hibernation type
Hibernation starting
P22.02
frequency
Set
Name
value
36
37
38
39
41
43
1.000
1.000
0.100
0.000
1.00
0.10
0.00
40.00Hz
Connect motor B variable frequency
Connect motor B power frequency
Connect motor C variable frequency
Connect motor C power frequency
Connect motor D power frequency
Connect motor E power frequency
Adjustable according to the actual
situations
Adjustable according to the actual
situations
Adjustable according to the actual
situations
Adjustable according to the actual
2
situations
Adjustable according to the actual
situations
Adjustable according to the actual
1
situations
Adjustable according to the actual
0
situations
Adjustable according to the actual
situations
Adjustable according to the actual
situations
Adjustable according to the actual
situations
1 HVAC function enabled
Hibernate according to the running
1
frequency
Allow hibernation only when the running
frequency is smaller than the value and
23
