Goodrive300-16 special inverter for HVAC
Function
Name
code
Jogging
P08.06
frequency
Jogging
P08.07
ACC time
Jogging
P08.08
DEC time
Jumping
P08.09
frequency 1
Jumping
P08.10 frequency
range 1
Jumping
P08.11
frequency 2
Jumping
P08.12 frequency
range 2
Jumping
P08.13
frequency 3
Jumping
P08.14 frequency
range 3
Traverse
P08.15
range
Sudden
jumping
P08.16
frequency
range
Traverse
P08.17
boost time
Detailed instruction of parameters
0.00Hz~P00.03 (Max.output frequency)
0.0~3600.0s
0.0~3600.0s
0.00Hz~P00.03 (Max.output frequency)
0.00Hz~P00.03 (Max.output frequency)
0.00Hz~P00.03 (Max.output frequency)
0.00Hz~P00.03 (Max.output frequency)
0.00Hz~P00.03 (Max.output frequency)
0.00Hz~P00.03 (Max.output frequency)
0.0~100.0% (relative to the set frequency)
0.0~50.0% (relative to the traverse range)
0.1~3600.0s
78
Appendix A
Default
Modify
value
○
5.00Hz
Depend
○
on
model
Depend
○
on
model
○
0.00Hz
○
0.00Hz
○
0.00Hz
○
0.00Hz
○
0.00Hz
○
0.00Hz
○
0.0%
○
0.0%
○
5.0s
