8 CONNECTING TO EXTERNAL DEVICES

The
HD
RANGER
through its interfaces:
Input/output data interface via mini-USB connector to USB memory or
PC.
Video/Audio analogue output interface via V/A connector output.
Video/Audio analogue input interface via V/A connector input.
DiSEqC interface via RF connector.
Next is described each of these interfaces and their interaction with external
devices.
8.1

Mini-USB connector

The equipment has a female mini USB port that uses a USB media specific
protocol called "On-the-Go" (OTG abbreviated). This type of communication
allows the equipment to work in two different ways depending on the device
connected to the USB port: as a server (host) or device (slave). More often, the
HD
RANGER
slave when connecting to a computer. This feature makes the equipment in a
much more versatile tool.
Connecting the
8.1.1
(slave)
This connection allows the user to copy files (screenshots, channel sets,
dataloggers, DiSEqC commands, installations) from the equipment to the USB
stick by following these steps:
Connect the CC-045 cable (USB (A) Female - Mini USB (A) Male) to
the mini-USB socket
Connect the USB stick to the female port of the cable.
USB icon should appear on the top right corner of the equipment. This
icon indicates that an USB stick has been detected at the port.
Press the Installations key
data to download.
8-86
can interact with external devices, sharing information
/+
will work as a host when connecting a USB memory and as
/+
HD
RANGER/
(see figure
(host) to an USB memory
+
5) of the equipment.
and select the installation where is the
