Promax HD RANGER+ Manual page 105

SAT IF TEST Function
Test frequencies
ATTENUATION TEST Function
band)
Test frequencies
VIDEO & AUDIO
Format
Aspect Ratio
SI/PSI data
HD Video Resolution
Audio
ANALOGUE SIGNALS MEASUREMENT
LEVEL MEASUREMENT
Measurement range
Terrestrial TV & FM bands
Satellite TV band
Attenuation scale
Numerical indication
Graphical indication
Measurement bandwidth
Audible indicator
Accuracy
Terrestrial bands
Satellite band
Out of range indication
RF MEASUREMENTS
Terrestrial bands
Analogue channels
Digital channels
Satellite band
Analogue channels
Digital channels
2
Function to be used with RP-250 or RP-050 IF multiple pilot generator.
3
Function to be used with RP-250 or RP-080 multiple pilot generator.
April 2013
2
(IF distribution network response for satellite band)
3 selectable pilots.
3
(Signal distribution network response for terrestrial
3 selectable pilots.
MPEG-2 (MP@HL) (Main Profile High Level). MPEG-4 AVC H.264.
16/9 or 4/3.
Service list and main PIDs.
1080, 720 and 576, progressive or interlaced.
MPEG-1, MPEG-2, HE-AAC, Dolby Digital and Dolby Digital Plus.
15 dBµV to 130 dBµV (3.16 µV to 3.16 V).
20 dBµV to 130 dBµV (31.6 µV to 3.16 V).
Auto-range.
Absolute value according to selected units.
Analogue bar on screen.
100 kHz.
Pitch sound. A tone with pitch proportional to signal strength.
±1.5 dB (25-120 dBµV, 45-1000 MHz) (22 °C ± 5 °C).
±1.5 dB (35-100 dBµV, 950-2050 MHz) (22 °C ± 5 °C).
<, >.
Level, Video-Audio ratio, Carrier-Noise ratio.
Channel power, Carrier-Noise ratio.
Level and Carrier-Noise ratio.
Channel power and Carrier-Noise ratio.
9-95
